Four Corners Peel-Off Sticky Mat
Four Corners Peel-Off Sticky Mat
Nabai’s peel off sticky mats support floor particle control with a segmented adhesive structure. The four-corner peel design allows selective layer replacement in high-contact areas. This layout helps maintain stable dust collection during daily traffic movement.
- Segmented peel structure: Individual corner sections support targeted replacement in worn areas.
- Extended usable surface: The layered design helps reduce full mat replacement during routine use.
- Stable particle collection: The adhesive surface captures dust and debris from shoes and cart wheels.
Key Features & Specifications
Application
- High-traffic cleanroom entrances, gowning areas, and material transfer stations in semiconductor, pharmaceutical, and biotechnology facilities with ISO Class 5-8 requirements.
Material & Construction
- Base Film: Premium-grade, tear-resistant Polyethylene (PE) with precision perforation technology
- Adhesive Layer: Uniformly distributed high-tack acrylic adhesive across all four quadrants
- Segment Design: Four identical triangular sections meeting at center point
- Backing: Enhanced non-slip rubber backing with full-area coverage
Available Colors
- Blue: Standard cleanroom identification
- White: Maximum contamination visibility
- Transparent: Pharmaceutical and biotech applications
- Gray: General industrial clean areas
Performance & Technical Data
| Feature | Description |
|---|---|
| Material | polyethylene |
| Viscosity | 250g-550g |
| Size | 18x24'', W450mm × L600mm 18x36'', W450mm × L900mm 18x45'', W450mm × L1143mm 24x36'', W600mm × L900mm 26x45'', W650mm × L1143mm |
| Thickness | 3C-6C |
| Layers | 1-30,1-60 |
| Color | blue,white,transparent,gray |
| Packing | 30 layers/piece, 10 pieces/box. 60 layers/piece, 5 pieces/box. |
| Place of application | Indoor |
How to Use
- Position Mat: Place mat at cleanroom entrance with arrows pointing toward traffic flow
- Remove Backing: Peel off bottom protective liner completely
- Secure to Floor: Press mat firmly onto clean, dry surface
- Activate First Corner: Remove protective film from one corner section only
- Rotate Usage: When first corner shows significant contamination, peel it off and activate the next corner
- Continue Rotation: Repeat process clockwise or counterclockwise through all four corners
- Full Replacement: When all corners are exhausted, replace entire mat
